POWERFUL.
EFFICIENT.
SILENT.
The Abyzz Effect!
Abyzz AFC flow pumps redefine new standards for reliability, efficiency, and power in professional aquatic applications.
Featuring an innovative design built with high-quality titanium and corrosion-resistant materials for continuous operation, the AFC flow pumps deliver precise, energy-efficient flow rates—ensuring optimal water movement and circulation for aquaculture facilities, large aquatic exhibits, and industrial applications.
Abyzz AFC Family
The Abyzz AFC line comprises three powerful flow pump models, each offering unmatched reliability, efficiency, and performance for a variety of aquatic environments. Built with robust, corrosion-resistant materials and featuring innovative electronics, every model provides precise, energy-efficient flow control. Despite differences in flow capacity and power, all three pumps share the same advanced design principles, ensuring minimal maintenance and a long service life—making them ideal solutions for aquaculture facilities, large aquatic exhibits, and industrial applications
Flow (Nominal): 55,000 lph
Flow (Maximum): 60,000 lph
Discharge Speed (Max): 3,3m/s
Rated Input: 4-150W
Operating Voltage: 200…240V~
Ambient Temperature: +1°C...+50°C
Maximum Immersion Depth: 2.5m
Pump Cable Length: 4m / 7m
IPU Driver Rating: IP65
Abyzz AFC150 IPU
The Abyzz AFC150 pump is a compact yet high-capacity option for mid- to large-scale aquatic eco-systems. It incorporates a medical-grade IPU driver and operates at a safety extra-low voltage (SELV) level, delivering robust water flow while helping protect both aquatic life and personnel. Its specialized propeller and built-in flow conditioner create a wide, laminar output that reduces turbulence and noise. With its reliable engineering, straightforward programming features, and quiet performance, the AFC150 provides a practical balance of power, safety, and efficiency.
Flow (Nominal): 55,000 lph
Flow (Maximum): 60,000 lph
Discharge Speed (Max): 3,3m/s
Rated Input: 4-150W
Operating Voltage: 200…240V~
Ambient Temperature: +1°C...+50°C
Maximum Immersion Depth: 2.5m
Pump Cable Length: 4m / 7m
IPU Driver Rating: IP65
Abyzz AFC150 IPU
The Abyzz AFC150 pump is a compact yet high-capacity option for mid- to large-scale aquatic eco-systems. It incorporates a medical-grade IPU driver and operates at a safety extra-low voltage (SELV) level, delivering robust water flow while helping protect both aquatic life and personnel. Its specialized propeller and built-in flow conditioner create a wide, laminar output that reduces turbulence and noise. With its reliable engineering, straightforward programming features, and quiet performance, the AFC150 provides a practical balance of power, safety, and efficiency.
The AFC150’s IPU driver offers a comprehensive set of features designed to ensure both safety and efficient operation. Its medical-grade power supply steps mains voltage down to a 12V safety extra-low voltage (SELV), reducing risk in interactive or high-safety environments. Engineered with an insulation rating of at least 4000V, the driver provides robust protection for operators, animals, and equipment alike. In addition, it boasts advanced control options, allowing users to fine-tune flow rates, schedules, and operational modes to match specific needs. Built for reliability and ease of use, the AFC150 IPU driver delivers precise performance alongside dependable safety.
Flow (Nominal): 165,000 lph
Flow (Maximum): 220,000 lph
Discharge Speed (Max): 3,3m/s
Rated Input: 4-400W
Operating Voltage: 200…240V~
Ambient Temperature: +2°C...+40°C
Maximum Immersion Depth: 8m
Minimum Immersion Depth: 0.6m
Pump Cable Length: 10m / 30m
Abyzz AFC400 IPU
For very large aquaria and mixing basins, we have designed the AFC1200IPU, which offers a flow rate of up to 550 m³/h (2,400gpm) while being even more silent than its smaller brother, the AFC400IPU. The much larger, 5-bladed propeller significantly reduces noise, making the AFC1200IPU for humans almost non-hearable under water.
Flow (Nominal): 165,000 lph
Flow (Maximum): 220,000 lph
Discharge Speed (Max): 3,3m/s
Rated Input: 4-400W
Operating Voltage: 200…240V~
Ambient Temperature: +2°C...+40°C
Maximum Immersion Depth: 8m
Minimum Immersion Depth: 0.6m
Pump Cable Length: 10m / 30m
Abyzz AFC1200
For very large aquaria and mixing basins, we have designed the AFC1200IPU, which offers a flow rate of up to 550 m³/h (2,400gpm) while being even more silent than its smaller brother, the AFC400IPU. The much larger, 5-bladed propeller significantly reduces noise, making the AFC1200IPU for humans almost non-hearable under water.
AFC Driver Model: AFC150
AFC Driver Model: AFC400 / AFC1200
Abyzz IPU Driver
For very large aquaria and mixing basins, we have designed the AFC1200IPU, which offers a flow rate of up to 550 m³/h (2,400gpm) while being even more silent than its smaller brother, the AFC400IPU. The much larger, 5-bladed propeller significantly reduces noise, making the AFC1200IPU for humans almost non-hearable under water.
High-quality Workmanship & durability
Abyzz pumps are characterized by innovative technology and high-quality materials. They offer a high flow rate with low power consumption. The pumps are quiet in operation and require very little maintenance thanks to integrated bearing flushing and silicon carbide bearings. Suitable for dry and submerged installation, even in sea water.
Tailored Solutions for Every Feature
-
Create clean, inviting water environments for safe and enjoyable recreational activities like swimming or boating.
-
Maintain visually stunning water features, ensuring the health of aquatic plants and ornamental fish while minimizing maintenance requirements.
-
Support biodiversity with tailored flow systems that replicate natural conditions, providing a haven for local wildlife such as frogs, turtles, and birds.
-
Ensure smooth operation and visual appeal for fountains, waterfalls, and other dynamic water features through optimised water flow and circulation.
Ponds and water features are central to the beauty of parks, gardens, and recreational spaces, enhancing both aesthetic appeal and biodiversity.
The innovative Abyzz A200 pump with its titanium impeller consists of powerful and programmable menu-controlled electronic driver and a sinusoidal three-phase synchronous motor (pump).
The motor operates at an efficiency factor of over 90% which, along with the fact that you can adjust the speed to meet your performance requirements, makes it an energy-saving solution to traditional power hungry higher voltage pumps.
The menu controlled driver and motor run on an mere 12V and because of that it can be used in a myriad of applications.
The integrated flushing bearing provides optimum protection against calcification (Calcium Carbonate deposits - CaCO3). In conjunction with the silicon carbide bearings and special hard metal shaft, this feature provides for low-maintenance operations.
The materials used to manufacture all of these components have been carefully selected so as to be harmoniously integrated into the overall design to look great, ensure a long operational lifetime, and meet the most demanding requirements and highest quality standards.
Automation & Real-Time Monitoring
Advanced control systems allow real-time monitoring and adjustment of water quality parameters, including pH, Temperature, ORP levels and more!
Manage water systems remotely, ensuring efficient operation and immediate response to any issues.
Call Us
Take charge of creating thriving ecosystems and streamlining water management—partner with Syntech Aquatics today and make your vision a sustainable reality.
